In this article on “14 Steps to Install kubernetes on Ubuntu 18.04 and 16.04” we are going to create Kubernetes cluster along with kubeadm on Ubuntu 18.04 (The same steps can be used for the Ubuntu 16.04 as well)
We are going to use two nodes
- Master node
- Worker node
- Reading time is about 20 minutes
- Vagrant 2.2.7 or latest – For installationi nstruction click here
- VM VirtualBox – For installation instruction click here
Step 1 – Start your vagrant box
As a minimum requirement for kubernetes installation we need –
- Master Node – 2 cpus, 2 GB Memory
- Worker Node – 1 cpu, 1 GB Memory
Use following Vagrantfile to spin up your vagrant box
Vagrant.configure("2") do |config| config.vm.define "master" do |master| master.vm.box_download_insecure = true master.vm.box = "hashicorp/bionic64" master.vm.network "private_network", ip: "188.8.131.52" master.vm.hostname = "master" master.vm.provider "virtualbox" do |v| v.name = "master" v.memory = 2048 v.cpus = 2 end end config.vm.define "worker" do |worker| worker.vm.box_download_insecure = true worker.vm.box = "hashicorp/bionic64" worker.vm.network "private_network", ip: "184.108.40.206" worker.vm.hostname = "worker" worker.vm.provider "virtualbox" do |v| v.name = "worker" v.memory = 1024 v.cpus = 1 end end end
Step 2 – Update host files on both master and worker node
master node – SSH into the master node
$ vagrant ssh master
Add host entry for master as well as worker node
[email protected]:~$ sudo vi /etc/hosts 220.127.116.11 master.jhooq.com master 18.104.22.168 worker.jhooq.com worker
Test the worker node by sending from master
[[email protected] ~]$ ping worker PING worker.jhooq.com (22.214.171.124) 56(84) bytes of data. 64 bytes from worker.jhooq.com (126.96.36.199): icmp_seq=1 ttl=64 time=0.462 ms 64 bytes from worker.jhooq.com (188.8.131.52): icmp_seq=2 ttl=64 time=0.686 ms
Test the master node by sending from worker
[[email protected] ~]$ ping master PING master.jhooq.com (184.108.40.206) 56(84) bytes of data. 64 bytes from master.jhooq.com (220.127.116.11): icmp_seq=1 ttl=64 time=0.238 ms 64 bytes from master.jhooq.com (18.104.22.168): icmp_seq=2 ttl=64 time=0.510 ms
Step 3 – Install Docker on both master and worker node
You need to install Docker on both the node.
So run the following installation command on both the nodes
Enable and start docker
[email protected]:~$ sudo systemctl enable docker Created symlink /etc/systemd/system/multi-user.target.wants/docker.service → /lib/systemd/system/docker.service. [[email protected] ~]$ sudo systemctl start docker
Check the docker service status
[[email protected] ~]$ sudo systemctl status docker ● docker.service - Docker Application Container Engine Loaded: loaded (/lib/systemd/system/docker.service; enabled; vendor preset: enabled) Active: active (running) since Thu 2020-04-23 19:10:59 UTC; 4s ago Docs: https://docs.docker.com
Step 4 – Disable the firewall and turnoff the “swapping”
We need to disable firewall as well as swapping on master as well as worker node. Because to install kubernetes we need to disable the swapping on both the nodes
[email protected]:~$ sudo ufw disable Firewall stopped and disabled on system startup [[email protected] ~]$ sudo swapoff -a
Step 5 – Install “apt-transport-https” package
To download the kubernetes and its public we need to install “apt-transport-https” package on both master as well as worker node
[email protected]:~$ sudo apt-get update && sudo apt-get install -y apt-transport-https
Step 6 – Download the public keys
We need to have the public keys for accessing packages on Google Cloud.
So run the following command to get the public keys on both master as well as worker node
[email protected]:~$ curl -s https://packages.cloud.google.com/apt/doc/apt-key.gpg | sudo apt-key add - OK
Step 7 – Add kubernetes repo
As a next step we need to add the kubernetes repo to both master as well as worker node
[email protected]:~$ sudo bash -c 'echo "deb http://apt.kubernetes.io/ kubernetes-xenial main" > /etc/apt/sources.list.d/kubernetes.list'
Step 8 – Install kubernetes
Now after adding the kubernetes repo we need to install the kubernetes on both mater as well as worker node
[email protected]:~$ sudo apt-get update && sudo apt-get install -y kubelet kubeadm kubectl
Step 9 – Enable and Start kubelet
Alright now we have installed the kubernetes, now we need to enable the kubelet support for both master as well worker node
[[email protected] ~]$ sudo systemctl enable kubelet [[email protected] ~]$ sudo systemctl start kubelet
Step 10 – Initialize the kubernetes cluster
Okay now we have reach to point where we have done all the prerequisite for initializing the kubernetes cluster.
Let’s run the kubernetes initialization command on only on master
[[email protected] ~]$ sudo kubeadm init --apiserver-advertise-address=22.214.171.124 --pod-network-cidr=10.244.0.0/16
Note down kubeadm join command which we are going to use from worker node to join the master node using token.
sudo kubeadm join 126.96.36.199:6443 --token g2bsw7.5xr3bqc21eqyc6r7 --discovery-token-ca-cert-hash sha256:39b2b0608b9300b3342a8d0a0e9204c8fc74d45b008043a810f94e4f1fb8861f
Step 11 – Move kube config file to current user (only run on master)
Use the following command to get the kube config file and put it under working directory.
[[email protected] ~]$ mkdir -p $HOME/.kube [[email protected] ~]$ sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config [[email protected] ~]$ sudo chown $(id -u):$(id -g) $HOME/.kube/config
Step 12 – Apply CNI from kube-flannel.yml(only run on master)
After the master of the cluster is ready to handle jobs and the services are running, for the purpose of making containers accessible to each other through networking, we need to set up the network for container communication
[[email protected] ~]$ wget https://raw.githubusercontent.com/coreos/flannel/master/Documentation/kube-flannel.yml
Note – But since we are working on the VMs so we need to check our Ethernet interfaces first.
Look out for the Ethernet i.e. eth1 which has a ip address 188.8.131.52(this is the ip address which we used in vagrant file)
[[email protected] ~]$ ip a s
1: lo: <LOOPBACK,UP,LOWER_UP> 2: eth0: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc fq_codel state UP group default qlen 1000 link/ether 08:00:27:bb:14:75 brd ff:ff:ff:ff:ff:ff inet 10.0.2.15 3: eth1: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc fq_codel state UP group default qlen 1000 link/ether 08:00:27:fb:48:77 brd ff:ff:ff:ff:ff:ff inet 184.108.40.206 4: docker0: <NO-CARRIER,BROADCAST,MULTICAST,UP>
Now we need to add the extra args for eth1 in kube-flannel.yml
[[email protected] ~]$ vi kube-flannel.yml
Searche for – “flanneld”
In the args section add : – –iface=eth1
- --iface=eth1 args: - --ip-masq - --kube-subnet-mgr - --iface=eth1
Apply the flannel configuration
[email protected]:~$ kubectl apply -f kube-flannel.yml
podsecuritypolicy.policy/psp.flannel.unprivileged created clusterrole.rbac.authorization.k8s.io/flannel created clusterrolebinding.rbac.authorization.k8s.io/flannel created serviceaccount/flannel created configmap/kube-flannel-cfg created daemonset.apps/kube-flannel-ds-amd64 created daemonset.apps/kube-flannel-ds-arm64 created daemonset.apps/kube-flannel-ds-arm created daemonset.apps/kube-flannel-ds-ppc64le created daemonset.apps/kube-flannel-ds-s390x created
Step 13 – Join worker nodes to master(only run on worker)
In the Step 10 we generated the token and kubeadm join command.
Now we need to use that join command from our worker node
[email protected]:~$ sudo kubeadm join 220.127.116.11:6443 --token g2bsw7.5xr3bqc21eqyc6r7 --discovery-token-ca-cert-hash sha256:39b2b0608b9300b3342a8d0a0e9204c8fc74d45b008043a810f94e4f1fb8861f
W0423 19:27:00.344480 18268 join.go:346] [preflight] WARNING: JoinControlPane.controlPlane settings will be ignored when control-plane flag is not set. [preflight] Running pre-flight checks [WARNING IsDockerSystemdCheck]: detected "cgroupfs" as the Docker cgroup driver. The recommended driver is "systemd". Please follow the guide at https://kubernetes.io/docs/setup/cri/ [preflight] Reading configuration from the cluster... [preflight] FYI: You can look at this config file with 'kubectl -n kube-system get cm kubeadm-config -oyaml' [kubelet-start] Downloading configuration for the kubelet from the "kubelet-config-1.18" ConfigMap in the kube-system namespace [kubelet-start] Writing kubelet configuration to file "/var/lib/kubelet/config.yaml" [kubelet-start] Writing kubelet environment file with flags to file "/var/lib/kubelet/kubeadm-flags.env" [kubelet-start] Starting the kubelet [kubelet-start] Waiting for the kubelet to perform the TLS Bootstrap... This node has joined the cluster: * Certificate signing request was sent to apiserver and a response was received. * The Kubelet was informed of the new secure connection details. Run 'kubectl get nodes' on the control-plane to see this node join the cluster.
Step 14 – Check the nodes status(only run on master)
To check the status of the nodes use
[[email protected] ~]$ kubectl get nodes
NAME STATUS ROLES AGE VERSION master Ready master 26m v1.18.2 worker Ready <none> 63s v1.18.2
So this was our beginner tutorial which involves around – 14 Steps to Install kubernetes on Ubuntu 18.04 and 16.04.
With that we can conclude what we have achieved –
- Congratulations we have successfully installed kubernetes on Ubuntu 18.04
- After installing kubernetes we are successfully join the worker nodes with master.
